Open Media Vault Docker

Jan 08, 2020 Then click “Upload” and upload the “openmediavault-omvextrasorg5.1.11all.deb” file. Now, search for the word “extra” in the search bar and you should see: “openmediavault-omvextrasorg 5.1.11” in the results. Check the box next to it and then click “Install”. Docker and Portainer. Out of the box, the OpenMediaVault software has support for (S)FTP, SMB/CIFS, DAAP media server, RSync, and even features built-in support for Docker containers. OpenMediaVault can be much easier to use than trying to set up each individual service on your Raspberry Pi, like SAMBA and FTP.

You can add more features & apps by simply selecting the software you need, wecall this plugins. Plugins are possible due to the modular design of openmediavault andare the prefered way to extend your NAS. It is still possible to install regularsoftware or containerized software like Docker. Plugins only exist for yourconvenience.


  • You signed in with another tab or window. Reload to refresh your session. You signed out in another tab or window. Reload to refresh your session. To refresh your session.
  • How to: Install docker on OpenMediaVault 5 (OMV5) easily & How to: Configure docker (Docker Storage) to use specific location to store files/container/images other than default location easily. The above guide explains how to install Docker on OMV 5, since we will use portainer here to manage docker for easier docker management.
  • Install RDesktop. First things, first. You’ll need to login to Portainer and open a new Stack. Next, paste the following in: You’ll only need to change the PUID, GUID, TZ, and the second volume option. You can find the PUID and GUID by opening Putty and logging into your server.

Compared to adding regular software, plugins offer the following benefits:

Openmediavault docker

Openmediavault Docker Setup

  • Easier to install - You just click on what you want.
  • Easier to configure - it is often preconfigured so you don’t have to.
  • Automatic updates - ensure Stability & Security.
  • A Webinterface - is added when needed for your ease of use.


The following is the list of official plugins by openmediavault.

  • ClamAV: Provides Clam AntiVirus (ClamAV). It is a free software, cross-platform and open-source antivirus software toolkit able to detect many types of malicious software, including viruses
  • Diskstats: Complementary plugin to extend system statistics collection by adding I/O statistic graphs.
  • Forked-daap: Provides a daap protocol music server.
  • LVM2: LVM managing. Create volume groups and logical partitions.
  • NUT: Controlling and configuring UPS. The driver support is based on NUT.
  • Shairport: Provides Airtunes emulator. Stream music wirelessly to your iPod/iPad/iPhone/iTunes.
  • ShareRootFs: Provides shared directories on root file system.
  • SNMP: Provides Simple Network Management Protocol (SNMP). SNMP is an Internet Standard protocol for collecting and organizing information about managed devices on IP networks.
  • TFtp: Provides Trivial File Transfer Protocol (TFTP). TFTP is a simple lockstep File Transfer Protocol which allows a client to get a file from or put a file onto a remote host.
  • USB Backup: Backup internal data to external disks on scheduled basis or on plug drive event.

3rd party¶

An overview of the third party plugin list can be found at


In this video/blog post we’ll look at how to install Plex on OpenMediaVault 5 using Docker and Portainer. We’ll also include the noexec fix while we’re at it to make sure that everything works without issue.

We’re going into this with the understanding that you’ve already setup OpenMediaVault 5 on a device. If you haven’t, go check out my other tutorials on how to do that and come back to this tutorial.

Getting Started

First thing, make sure you have your system up to date with all the latest updates.

Next, head over to and click on the link for OMV version 5. Then look for the link called “openmediavault-omvextrasorg” and click it. Click the newest version. In my case, it is “5.2.1”. Then click the “Files” tab at the top of the page. Then click “pool”, “main”, and “o”. Next click “openmediavault-omvextrasorg”. On this page, you should see a couple of options. Click the file that ends in “.deb” to download the file.

Go back to your OpenMediaVault installation and click on “Plugins” and then click the “Upload” button on that page. Upload the .deb file you just downloaded. Once that is complete, search for “extras” in the search field at the top of the page.

Check the box next to “openmediavault-omvextrasorg 5.2.1” and click the “Install” button at the top of the page.

Now reboot the system.

Once the system has rebooted, you can log back in. Click the new “OMV-Extras” link in the left sidebar. Click on “Docker” in the blue bar. Then click the dropdown that says “Docker” and click “Install”. Once that has completed, click the “Portainer” dropdown and click “Install”.


Fixing noexec

Now open an SSH program like Putty and login to your server using root.


nano /etc/openmediavault/config.xml

Then do a search for “mntent”

You should be brought to a section that is a different color because it is commented out. Use your arrow keys to press down until you get to the next section and look for the “<opts>” line and remove the “noexec” option from that line. Then press CTRL+X and then press Y to confirm.

That will bring you back to the main screen of your Putty program. While you’re there, type this:

omv-salt deploy run fstab

Press Enter on your keyboard. It will look like nothing happened and that’s fine. Now type in:


And then press Enter on your keyboard.

Once the system has rebooted, you can log in to the server via Putty again using root and type in:

cat /proc/mounts

Then look for your hard drives (sda1 or sdb1) and make sure there is no “noexec” in any of the lines associated with your hard drives.

Create Shares

You’ll need to go your OpenMediaVault user interface and click “Shared Folders”

Create each of the following:

Open media vault docker serviceOpen Media Vault Docker
  • Config
  • Movies
  • TV
  • Music

Open Media Vault Docker Container

The “Config” folder is the only required folder. You can adjust your media folder names to fit your needs, but these are the defaults.

Make sure the permissions for each of the folders is set to “Everyone: read/write”.

Hover over any of the header titles (Name, Device, Relative Path, etc) and click the dropdown arrow. Then hover over “Columns” and check the box that says “Absolute Path” as we’ll need that later.

Then go to “SMB/CIFS”. Make sure this is set to “Enable” and then go to “Shares” in the blue bar.

Click “Add” for add each of the folders you created a moment ago and make sure the “Public” setting is set to “Only guests”.

Click “Save” after each one and once you have all your folders saved, you can click the “Apply” button in the yellow bar at the top of the page.

Post Continues After This Ad Break:

Ad Break

Post Continues Here:

Install Plex

Now go back to your OpenMediaVault server and login to the user interface.

Click on “OMV-Extras” and then click “Docker” in the blue bar. Then click the “Portainer” dropdown and click “Open web”.

Tell it that you want to control a local server. Then click on the section that says local.

Click “Containers”. Then click “Add container”

In a separate browser window, open this link:

In the “Create Container” window, fill in each of the fields based on the “docker-compose” information in the linuxserver/plex page.

You’ll need to open Putty again to get your UID and GID.

Under “Volumes” click “map additional volume” 1 time for each of the folders you created. Click the blue “bind” button for each one as well.

For the “Config” folder, you’ll type:


in the “container” field. Then you’ll type the absolute path of that from the “Shared Folders” page on your OpenMediaVault page and append it with /Plex. Mine looks like this with all the folders added:

Next, click the “Network” tab and change the setting from “Bridged” to “Host”.

You’ll move to the “Env” tab next and enter the PUID, PGID, VERSION, and UMASK_SET options. Mine looks like this:

Next, go to the “Restart policy” tab and change it to “Unless stopped”.

That’s it. Now you can click the “Deploy the container” button right above the “Advanced container settings”

Once it has completed, you can go to http://your-server-ip:32400/web/index.html

Sign Into Plex

Now you will be asked to sign into Plex and claim your server. Do that.

Next you will add your media folders and give each a name for Plex. Once you have done that, you can add users and assign permissions for each user to be able to access whatever folders you want them to be able to access and then you’re done.
